| SYS-8026B-TRF |
- SuperServer 8026B-TRF (Black)
|
| |
|
Super X8QBE-F |
| |
|
| CPU |
- Quad 1567-pin LGA Sockets
- Supports up to four Intel® Xeon® 64-bit processor(s) of the same type below:
- Intel® Xeon® Processor 7500 Series (Nehalem-EX)
|
| QPI |
|
| |
|
| Memory Capacity |
- 32x 240-pin DIMM sockets
- Supports up to 512 GB DDR3 ECC Registered memory at 1066/978/800MHz speed
- Memory Mirroring supported
|
| Memory Type |
- 1333* / 1066 / 800MHz ECC Registered DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
|
| DIMM Sizes |
- 1GB, 2GB, 4GB , 8GB , 16GB
|
| Memory Voltage |
|
| Error Detection |
- Corrects single-bit errors
- Detects double-bit errors (using ECC memory)
- Supports Intel® x4 and x8 Single Device Data Correction (SDDC)
|
| |
|
| Chipset |
- Intel® 7500 (Boxboro-EX) chipset
- ICH10R
|
| SATA |
- Intel ICH10R SATA 3.0Gbps Controller
- RAID 0, 1, 5, 10 support (Windows)
- RAID 0, 1, 10 support (Linux)
|
| IPMI |
- Support for Intelligent Platform Management Interface v.2.0
- IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
- Winbond® WPCM450 BMC
|
| Network Controllers |
- Intel® 82576 Dual-Port Gigabit Ethernet Controllers
- Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
- 1x Realtek RTL8201N PHY (dedicated IPMI)
|
| Graphics |
|
| Super I/O |
|
| |
|
| LAN |
|
| USB |
- 2x USB rear ports
- 2x USB internal headers (3 ports)
- Total 5 USB 2.0 Compliant
|
| VGA |
|
| Serial Port / Header |
- 1 Fast UART 16550 serial port
- 1 Fast UART 16550 serial header
|
| |
|
| BIOS Type |
- 32Mb SPI Flash EEPROM with AMI® BIOS
|
| BIOS Features |
- Plug and Play (PnP)
- PCI 2.2
- ACPI up to 3.0
- USB Keyboard support
|
|
 |
|
|
| Form Factor |
|
| Model |
|
| |
|
| Height |
3.5" (89mm) |
| Width |
17.2" (437mm) |
| Depth |
27.9" (709mm) |
| Weight |
Gross Weight: 66.5 lbs / Net Weight: 40 lbs |
| Available Colors |
Black |
| |
|
| Buttons |
• Power On/Off button
• System Reset button |
| LEDs |
• Power LED
• Hard drive activity LED
• 2x Network activity LEDs
• System Overheat LED
• Power fail LED |
| |
|
| PCI-Express |
- Auto-switch for 2 (x16) PCI-E 2.0 or 1 (x16) PCI-E 2.0 + 2 (x8) PCI-E 2.0 or 4 (x8) PCI-E 2.0 slots
|
| |
|
| Hot-swap |
- 6x 3.5" Hot-swap SAS/SATA Drives Supported
|
| |
|
| 1x 2U SAS / SATA backplane w/ SES-II |
| |
|
| DVD-ROM |
- Slim 8x DVD, 24x CD, DVD-ROM (optional)
|
| |
|
| Fans |
3x 80mm heavy-duty fans with optimal fan speed control; 1x Air shroud |
| |
|
| Redundant 1400W high-efficiency power supply with PMBus |
| AC Input |
- 1200W: 100 - 140V, 50 - 60Hz, 10.5 - 14.7 Amp
- 1400W: 180 - 240V, 50 - 60Hz, 7.2 - 9.5 Amp
|
DC Output
+5V standby |
|
DC Output
+12V |
- 100 Amp @ 100-140V
- 117 Amp @ 180-240V
|
| Certification |
80 PLUS Gold Certified
[ Test Report ] |
| |
|
| CPU |
- Monitors for CPU Cores, +1.2V, 1.5V, +3.3V, +12V, (+3V, 1.0V, 1.2V, 1.8V, 1.1V) Standby, VBAT, Memory, Chipset Voltages.
- 4-Phase-switching voltage regulator with auto-sense from 0.6V-1.35V
|
| FAN |
- 10x 4-pin fan headers with tachometer status monitoring
- Low noise fan speed control mode
|
| Temperature |
- Monitoring for CPU and chassis environment
- Thermal Control for 10x fan connectors
|
| Other Features |
- Chassis intrusion detection
|
| |
|
| Environmental Spec. |
- Operating Temperature: 10° to 35° C (50° to 95°F)
- Non-operating Temperature: -40° to 70° C (-40° to 158° F)
- Operating Relative Humidity: 8% to 90% (non-condensing)
- Non-operating Relative Humidity: 5 to 95% (non-condensing)
|
|
